Cold Storage Cold Room Cooling System , Blast Freezer Room For Meat And Fish

Regular price
$4,761.99
Regular price
$4,771.99
Sale price
$4,761.99
Earn 2380 Reward Points. Learn More...
Terms & conditions
Order in the next
to get it by
Details
  • SKU: 1005007523770533
  • Brand: Bulky Best - Wholesale shopping made EASY!
  • Type:
  • Availability: In Stock
Description
  • Brand Name : NoEnName_Null
  • Hign-concerned Chemical : None
  • Origin : Mainland China
  • Applicable Industries : Machinery Repair Shops
  • Temperature : -60C~+20C
  • Place of Origin : Zhejiang, China
  • Brand Name : Odin
  • Voltage : 220v-380v
  • Dimension(L*W*H) : 3mx3mx2m
  • Weight : 1000kg
  • Warranty : 1 Year
  • Key Selling Points : Sustainable
  • Compressor brand : Bitzer
  • Panel Thickness : 120mm
  • Cooling Capacity : 50ton
  • Machinery Test Report : Provided
  • Video outgoing-inspection : Provided
  • Warranty of core components : 1 Year
  • Core Components : Pressure vessel
  • Local Service Location : Egypt, Canada, Turkey, United Kingdom
  • Showroom Location : Egypt, Canada, Turkey, United Kingdom
  • Condition : New
  • After-sales Service Provided : Free spare parts
  • Marketing Type : New Product 2020
  • Certification : CCC
Product Description
Polyurethane insulation board design for cold room, the main steel structure to facilitate construction. Portable sliding doors,
and out of cold storage more convenient, easy to operate.

Room Size:
1.small:<500m3
2.middle:500m3~5000m3
3.big :>5000m3

Tempreture Table For Reference:
1. processing room:10℃
2. fruit, vegetable, dry food:0℃~-5℃
3. medicine, cake, pastry, chemical material:0℃~-5℃
4. ice storage room:5℃~-10℃
5. fish, meat storage:-18℃~-25℃
6. deep freezer : -25℃~-35℃
Projects:
(1) Temperature range: -60ºC~+20ºC are all available.
(2) Size: Customize.
(3) Functions: fresh-keeping, freezing, quick-freezing, fire-proof, explosion-proof, air-conditioning are all available.
(4) Fully automatic control system.
(5) Easy to install and dismantle
(6) Temperature Alarm
(7) Data Logger
(8) PLC electric control ( LG,SIMENS, OMRON..famous parts)
(9) Refrigerant:R22,R404a,R410,R134a
(3) Insulation Panel: PU
Cold room insulation panel:use 100%polyurethane insulation panel,density about 38~46kg/m3,with gasket,with flame retardant,
fire-resistant panel thickness:50mm~200mm, standard width of panel is 960mm
1.office Foam panel:50mm thickness
2.processing room 10℃:50mm/ 75mm PU
3.5℃:75mm/ 100mm PU
4.-18℃:100mm/ 150mm PU
5.-25℃/ -35℃:150mm/200mm PU
6.panel steel cover:SS, GI, aluminum etc
(4)Doors:
1.Swing door and sliding door for choice.
2.Swing door:manual opened,automatic,etc.
3.Door board made with special pressing technology PU material.
4.Door frame:color steel or stainless steel.
5.Surface material:color steel or stainless steel with protecting film.
(5) Other accessories:
world-famous brands, like Danfoss, Castle, Every Control, Siemens, LG,Schneider

Our strengths:
1 Focus on refrigeration equipments about 20 years. We make our products by heart.
2 Strong R&D department make sure reasonable design and excellent quality.
3 Strict QC make sure product quality.
4 24 hours online service.
5 High efficiency team work.
6 Provide OEM service
